Usage:
Professionals, stages, tv, events ect.
Our X-F1800 is a flameprojector with a moving jethead that can turn 210° from left to right (-105 - +105°) in 340ms. More than 70 pre-installed sequences can directly be started.
The projektor can be controlled viaDMX, our ZK6200 or an ignition impulse of an external ignition system, 9-60 Volt. It is fueled with bioethanol which is brought into the device by a high-pressure pump and then shot out precisely.
The device can create flames up to 10m height. The fuel tank has a capacity of 10 liters. To guarantee a safe use the device is equipped with a tilt sensor, pressure monitor, safetywarning and a consumption alarm.
X-F1800 can work via Powercon or 12 Volt (battery input). There is a 5-Volt-exit to directly connect Wireless DMX. Thus the flamer can work completely wireless.
Scope of supply:
X-F1800 Circle Flamer
Case
Wheels
10 liter Tank
Dimensions: 590mm x 360mm x 370mm
Weight: 35kg
Effect height: 10m
Control: DMX, 3 or 5 pol. or Controller ZK6200
Connections: Neutrik
Power consumption: 350W
Consumption: 60ml/sec.
Working temperature: -10°C to 50°C
Case: Metall
GTIN (EAN) 9120082400213
CE-Zertificate
CE-Zertificate
RoHS
Usage: Professionals, stages, tv, events ect.
X-F3600 is a flameprojector with a moving jethead that can turn 360° in a circle. One complete turn takes 480ms. More than 94 pre-installed sequences can directly be started.
The projektor can be controlled viaDMX, our ZK6200 or an ignition impulse of an external ignition system, 9-60 Volt. It is fueled with bioethanol which is brought into the device by a high-pressure pump and then shot out precisely.
The device can create flames up to 10m height. The fuel tank has a capacity of 10 liters. To guarantee a safe use the device is equipped with a tilt sensor, pressure monitor, safetywarning and a consumption alarm.
X-F3600 can work via Powercon or 12 Volt (battery input). There is a 5-Volt-exit to directly connect Wireless DMX. Thus the flamer can work completely wireless.
Scope of supply:
X-F3600 Circle Flamer
Case
Wheels
10 liter Tank
Dimensions: 640mm x360mm x370mm
Weight: 35kg
Effect height: 10m
Control: DMX, 3 or 5 pol. or Controller ZK6200
Connections: Neutrik
Power consumption: 350W
Consumption: 60ml/sec.
Working temperature: -10°C to 50°C
Case: Metall
GTIN (EAN) 9120082400220
CE-Zertificate
CE-Zertificate
RoHs
uFlamer is a global pioneer of vertical fluid driven flamer, with flame height up to 8-10m. Equipped with built-in fuel tank and pumping system makes it super easy to setup and operate. The fuel for uFlamer is ISOPAR, which is much safer as well as less restrictions comparing with existing gas flamers on the market.IPX3 rated design and indoor nozzle optional ensure flexible usage of uFlamer.
Features
Fluid driven vertical flamer original designed by SHOWVEN
Flame up to 8-10m (no wind)
Super compact pumping system design, easy carrying
Stainless steel housing, reliable and durable
IPX3 waterproof design
Built-in 5L fuel tank, equals to 83s effects. Support external tank
No external hose connection needed, easier for setup
Safety lock with switchable test mode, safer for service
Tilt protection, the tilt sensor will be activated when machine slant Over 45°.
Intelligent control system, safer for use
Standard DMX control
Machine running status monitoring with SHOWVEN host controller
Built-in battery design (Optional, and customer can buy battery locally)
Dimensions: 330 x 260 x 320 mm
Weight: 14kg
Input and Power: 100-240VAC, 50/60 Hz 300W
Housing Material: 304 stainless steel
Effect Direction: Vertical
Flame Height: 8-10m (no wind)
Fuels: ISOPAR G, H, L, M, ISOPROPANOL
Fuel Tank Capacity: 5.0L
Fuel Consumption Rate: Nozzle M: 60ml/s
Interface: NEUTRIK POWERCON TRUE1 IN/OUT Waterproof 3-pin and 5-pin XLR IN/OUT
Control: DMX
Ignition: High Voltage Electron Ignition
Built-in Battery Design: Yes, Battery optional
Waterproof Level: IPX3
CE-Zertificate
CE-Zertificate
CE-Zertificate
Manual
uFlamer Volcano is five-heads plug and play liquid flamethrower, with each head can be controlled independently. Volcano with more than 90 preset firing sequences, 25L built-in stainless steel fuel tank, and support automatic refueling system. It is an ideal choice for fireworks displays, outdoor concert, opening ceremony, sports, scenic area etc.
Features
5-heads liquid flamer
Independent control of each head
Internal pump, plug and play system
Flames up to 10m
Reinforced stainless steel housing
25L built-in stainless steel fuel tank
Support automatic refueling station
Real-time fuel level display, both electronically and mechanically
Safety switch
Integrated valve block design
Customized water-proof ignitor
IPX3 rain-proof, can be used in rain
DMX control, with both 3-pin and 5-pin XLR port
Compatible with fireworks firing system
Dimensions: 630 x 450 x 400 mm
Weight: 48kg
Input and Power: 200-240VAC, 50/60 Hz 100 -120VAC, 50/60 Hz
Work power 2000W
Single head flame height 8-10m
Flame angles 5
Fuel ISOPAR G, ISOPROPANOL
Built in fuel tank capacity 25L
Ignition High voltage electron ignition Control DMX, Fireworks firing system
Water proof level IPX3
Interface 3-pin and 5-pin XLR
CE-EMC
Spec
User Manual
uFlamer Gasboom is the safest gas flamer ever on the market, with a series of safety features including 0.1s super sensitive flame monitoring, cascadable power cut-off E-stop connector, dual high voltage electron igniter, patented “SFT” technology, safety lock, dual magnetic valves, shut-off valve, ARM warning light etc. With 5 types of nozzles optional, 2/4 built-in gas cartridges positions, flame effect height from 2 to 8m ensure versatile applications for both indoor and outdoor events.
Features
Dimension: 320 x 310 x 325 mm
Weight: 13 kg
Input and Power: 100-240VAC, 50/60 Hz
200W
Housing Material: 304 stainless steel
Effect Direction: Vertical
Flame Height: 2-8m (canister QTY, nozzle size etc)
E-Stop Interface: Yes, can be connected in series
Dual Magnetic Valves: Yes, connect in series
High Sensitive Flame Monitoring: Yes, sensitivity up to 0.1s
Interface: NEUTRIK POWERCON TRUE1 IN/OUT
Waterproof 3-pin and 5-pin XLR IN/OUT
Control: DMX 512, 9-60V voltage input
Wireless, with Wirelss DMX Receiver (5-PIN DMX IN with DC5V power supply)
Ignition: High Voltage Electron Ignition * 2
Built-in Battery Design: Yes, 4*18650 Lithium cells
Waterproof Level: Can be used in heavy rain
Firing Duration: 0.1-10s
Fuel: LPG propane or butane gas, gas cartridges bottle, aerosol cartridges
Cartridge Holder: Twin cartridge holder with 2 shut-off valves and 2 non-return valves
Quadruple cartridge holder with 4 shut-off valves and 4 non-return valves (optional)
Micro Filter: Yes, installed between shut-off and non-return valves
Spec
The FXcommander is designed to be a professional while intuitive control solution for SFX and Pyro engineer, it allows to control all DMX device such as SPARKULAR, FLAMER, FOG, HAZE, CONFETTI etc. in a safe and professional way. Together with our original slaves it can also programming fireworks display wirelessly. Take advantage of the 10.1 inch capacitance touch screen and powerful software system, it allows FX operators edit a show in a few minutes, everything in the system are intuitively designed, no lighting console operation background needed. Large scale shows with special effects and fireworks can be sync with music precisely through our professional windows software FXcommander_Editor. The FXcommander is setting the safety standard for the special effects control.
Features
Professional DMX & Pyro Console
A dedicated console for SFX device and fireworks set off
Customized for SFX operator to control FX device professionally and safely
Next Level Safety for Special Effects Control
Pyro arm switch, DMX arm switch, Deadman button ensure zero false trigger
PANIC - Emergency stop at any time
Safety channel specially designed for SFX device
Dual antenna, ensure fast, stable and reliable PYRO signal transmission
RDMX communication with SHOWVEN device, device status real time monitoring
8 keyboard shortcut key, can set to tap or lock mode, ensure quick and reliable trigger
Intuitive Programming and Operation
10.1" capacitance touch screen
Presetting device and effect lib for fast programming
5 preset effect rules for easier programming
Easy and fast improvisation programming
Convenient manual pyro firing edit
Demonstration function for programmed show
Powerful
Scene switch, max. support 4 scenes, each scene support 128 cues
USB port support software update, show file update and backup, device lib update etc.
Variety interfaces: 3-pin and 5-pin DMX, MIDI input, LTC input, Audio Output, USB
Wireless: 2.4GHz wireless DMX signal, dual band wireless pyro signal
Battery driven with built in battery Windows FXcommander_Editor Software can generate project list table, minimize operator’s workload.
Precise Control and Sync with Music
Dual-core processor, smooth operation
MIDI, LTC receiver, support SMPTE time code
Windows FXcommander_Editor Software ensure precise programming
Built-in audio signal output, achieve accurate synchronization between music and effects
Personalization Settings
Multi language optional
Unlimited self-editable colors
User defined CUE icon
Dimensions: 314×270×65mm mm
Weight: 4kg
Input: 100-240VAC, 50/60 Hz
Work Power: 20W
Casing material: Aluminium
Battery powered: yes
Wireless function:
2.4G wireless DMX
Dual band wireless PYRO
Interface:
1x USB
1x USB Download
1x LAN
1x Audio Output
1x MIDI IN
1x LTC IN
1x 3-PIN DMX OUT
1x 5-PIN DMX OUT
1x External Trigger
CE-RED
ROHS
User Manual
Spec
